#include <IDianaContinuation.hpp>
Public Member Functions | |
| virtual ContiReturn | Continuate ()=0 throw (Common::Error::ECapeUnknown, Common::Error::ECapeSolvingError) |
| virtual void | AddFreeParameter (const Common::Types::CapeString &strParName, Common::Types::CapeDouble minValue=0.0, Common::Types::CapeDouble maxValue=0.0)=0 throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) |
| virtual void | RemoveFreeParameter (const Common::Types::CapeString &strParName)=0 throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) |
| virtual Common::Types::CapeString | GetVariableName (Common::Types::CapeLong index)=0 throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) |
| virtual std::vector < std::complex < Common::Types::CapeDouble > > | GetEigenvalues ()=0 throw (Common::Error::ECapeUnknown) |
Detailed Description
Base interface of the Diana continuation algorithms.
Member Function Documentation
| virtual void AddFreeParameter | ( | const Common::Types::CapeString & | strParName, |
| Common::Types::CapeDouble | minValue = 0.0, |
||
| Common::Types::CapeDouble | maxValue = 0.0 |
||
| ) | throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) [pure virtual] |
Adds "free" parameter (the possible variants are continuation parameter, unfolding parameters, etc). Such parameters are sused as state variables in the continuation.
- Parameters:
-
strParName is the name of the continuation parameter. maxValue parameter maximum value. minValue parameter minimum value.
- Note:
- if minValue and maxValue equals 0.0 then will be used values defined in the model.
Implemented in DianaContinuation.
| virtual ContiReturn Continuate | ( | ) | throw (Common::Error::ECapeUnknown, Common::Error::ECapeSolvingError) [pure virtual] |
Main continuation method.
- Returns:
- Continuation return code ContiReturn
Implemented in DianaContinuation, SingAnalyser, and HopfPointContinuation.
| virtual std::vector<std::complex<Common::Types::CapeDouble> > GetEigenvalues | ( | ) | throw (Common::Error::ECapeUnknown) [pure virtual] |
Returns eigenvalues of the generalized eigenvalues problem (PhD thesis, section 2.3) or Floquet multipliers (PhD thesis, section 3.2 )
Implemented in DianaContinuation, and SteadyStateContinuation.
| virtual Common::Types::CapeString GetVariableName | ( | Common::Types::CapeLong | index | ) | throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) [pure virtual] |
Returns name of the variable by index.
Implemented in DianaContinuation, SingAnalyser, HopfPointContinuation, and SteadyStateContinuation.
| virtual void RemoveFreeParameter | ( | const Common::Types::CapeString & | strParName | ) | throw (Common::Error::ECapeUnknown, Common::Error::ECapeInvalidArgument) [pure virtual] |
Removes "free" parameter.
- Parameters:
-
strParName is the name of the parameter
Implemented in DianaContinuation.
The documentation for this class was generated from the following file:
